Automatic Empty Can Rinsing Machine Stainless Steel Structure

Automatic Empty Can Rinsing Machine / Stainless Steel Structure

Can rinsing machine description:

This machine is designed to use high pressure cleaning water to wash the empty can inside, which

can remove the dusts and garbage in the empty can before filling, so the product can reach higher

hygiene standards. A lot of Countries and regions have enacted regulations mandating that empty

containers must be cleaned before filling, such as beer production, so this idea rinsing machine can

satisfy this production demands.

This machine model is designed for empty can, we also have other machine types suitable for glass

bottle, plastic bottle, stainless steel bottle...etc, you can contact us for more details.

Can filling machine features:

1. This machine has smooth running, good rinsing effect, beautiful and generous shape, convenient

operation and maintenance, etc.

2. Cleaning water used for rinsing machine will be delivered into machine by pipes, and our machine

will pump the water into rinsing position automatically.

3. Gear transmission type is adopped by this machine.

4. High efficiency, low noise, long service life, convenient maintenance, full lubrication.

5. It uses frequency converter to control the machine running speed.

6. It adopts chain belt to achieve empty can inlet and outlet of the machine.

7. Empty can running way is guided by high quality guilding belt, and it is very easy to be changed if

customer have another one type can.

8. PLC automatic control, easy to operate, fault online display function.

Can rinsing machine electrical configuration:

Can rinsing machine details description:

Empty can inlet:

It adopts strong chain belt to achieve empty can moving, different chain belt such as plastic type, stainless

stell type, and wide type chain belt will be used for different bottles.

Can transferring:

Empty cans will be delivered to working positions by star wheel which is made of polymer plastic materials

that meet food production standards, in the same way, empty cans after washing will also be transferred by

food production standard star wheel.

Can risning:

Empty cans will be caught in the self-opening clip and then turned 180 degrees until the bottle mouth is facing

down, then cleaning water will be pumped into can inside to wash dustcs and garbage away, and we will have

some working positions to drip liquid drops out of cans. In this way, not only the irrigation effect is guaranteed,

but also the influence of the irrigation water on the subsequent filling taste is reduced.

Thanks!

For more information please contact us!

380V 50HZ Can Rinsing Machine

Automatic Empty Can Rinsing Machine

Stainless Steel Can Rinsing Machine

Automatic Empty Can Rinsing Machine Stainless Steel Structure Images
